Specifications
Base Material:: Aluminum Based
Copper Thickness: 0.5oz, 1.0oz, 2oz, 3oz
Service Type: OEM/ODM
Min. Hole Size: 0.25mm(10mils)
Surface Finishing: HASL,OSP,ENIG, Gold Finger
V-CUT Angle: 20, 25, 30, 45 Degree
Product Description

PCB board Manufacturer Electronic Components Printed Circuit Board MC PCB


An Aluminum Printed Circuit Board typically contains copper foil, thermal insulating layer and metal substrate, its structure divide into three layers:

  1.  Circuit layer: the equivalent of an ordinary PCB- copper thickness from 1oz to 10oz.
  2.  Insulation layer: Insulation is a layer of thermal insulating material with low thermal resistance. Thickness: 0.003 “to 0.006” inch is the aluminum PCB core technology.
  3.  Base Layer: a metal substrate, usually aluminum or copper.

Benefits of Aluminum Based Printed Circuit Boards

  1.  Low cost: Aluminum is a metal that can be found in a variety of climates, so it is easy to mine and refine. Therefore, the costs of doing so are significantly lower than other metals. In turn, this means that manufacturing products with these metals are less expensive as well.
  2.  Environmentally Friendly: Aluminum is non-toxic and recyclable. Manufacturing with aluminum is also conducive to conserving energy due to its ease of assembly. For printed circuit board suppliers, using this metal helps maintain the health of our planet.
  3.  Heat dissipation: High temperatures can cause severe damage to electronics, so it is wise to use a material that can help dissipate heat. Aluminum can actually transfer heat away from vital components, thus minimizing the harmful effect it could have on the circuit board.
  4.  Higher durability: Aluminum provides strength and durability to a product that ceramic or fiberglass bases cannot. Aluminum is a sturdy base material that can reduce accidental breakage during manufacturing, handling, and everyday use.
  5.  Lightweight: For its incredible durability, aluminum is a surprisingly lightweight metal. Aluminum adds strength and resilience without adding on any additional weight.



Product TypeAl Clad PCB 1 layer~2 layer
Maximum Panel size20"*24" (1170mm*600mm)
Copper thickness0.5oz, 1oz, 2oz, 3oz and 4 oz
Dielectric Thickness
(to Substrate)
0.05mm, 0.075mm, 0.1mm,0.15mm,0.2mm
Substrate Core Thickness0.4mm,0.6mm, 0.8mm, 1.0mm, 1.2mm, 1.5mm,2.0mm, 3.0mm and 3.2mm
Finished Board Thickness0.4mm To 4.0mm
Thickness Tolerance+/-10%
Aluminum MachiningDrilling,Tapping,Milling,Routing, Die-Punching,break-off tab available
Min. Finish hole size0.25mm
Max.working voltage2.5kVDC(0.075mm Dielectric), 3.75kVDC (0.15mm Dielectric)
Min.Track Width0.2mm (8mils)
Min.Track gap0.2mm (8mils)
Min. SMD pad pitch0.2mm (8mils)
Surface FinishingHASL, HASL Leadfree, Immersion gold, Flash gold, OSP
Soldermask colorWhite, Black, others Available
Legend colorBlack, White, others Available
EtestYES
RohsYES
Reference StandardIPC-A-600G Class 2
Special holesSpot facing, Cup holes
Data InputGerbers, AutoCad, Cam350, PROTEL 99SE,PROTEL DXP,
POWER PCB,ODB+.(TGZ)
