RoHS Circuit Board Manufacturer Aluminum Base 2835 LED SMD PCB Board
2PCS
MOQ
large.img.alt
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: Yizhuo
Certification: CE,ROHS,UL
Model Number: Aluminum Pcb Board 01
Payment & Shipping Terms
Packaging Details: Vacuum Package+ Good quality carton box
Delivery Time: 10-12 work days
Payment Terms: T/T, Western Union
Specifications
Brand Name: Yizhuo
Base Material: Aluminum Base
Copper Thickness: 1/2OZ
Peelable: 0.3-0.5mm
Profiling Punching: Routing, V-CUT, Beveling
Service: One-stop Service
Product Description

RoHS Circuit Board Manufacturer Aluminum Base 2835 LED SMD PCB Board

Product Description:

Aluminum base copper-clad laminate has excellent flame retardant, high mechanical strength, dimensional stability, etc. Especially it has a very good heat sink, electromagnetic shielding, and solder float.
It's widely used for the modifier and sparker on fire for motorcycle and mobile, power LED, sound box, power supply module, and acoustics shielding system, etc.
Note: We specially produce Metal Base Copper-Clad Laminates, and our products have been compiled series with all complete specifications.
The tapy and specification of Aluminum-based Laminates CCAF-01, CCAF-04-A, CCAF-05etc. And 0.8mm, 1.0mm, 1.5mm, 2.0mm, etc.
Thickness of the copper: 18um, 35um, 70um, 105um.
Base size: 500mm ×, 600mm (20"×, 24"); 600mm ×, 1060mm (24"×, 42")
CCAF-01 Aluminum-base copper-clad laminate
The test base: CCAF-01 the high heat dissipation Aluminum-base copper-clad laminate
The thickness of the copper: 35um
The thickness of the dielectric: 70um
The thickness of the aluminum base: 1.5mm
The result of the test:
RoHS Circuit Board Manufacturer Aluminum Base 2835 LED SMD PCB Board 0
Technique parameter:
Item Test item Technology request Unit Test result
1 Peel Strength A ≥ 1.8 N/mm 2
After thermal stress (260ordm;C) ≥ 1.8 N/mm 1.8
2 Blister test AfterThermal stress (260ºC, 2min ) No delaminating / Ok
3 Flammability(A) FV-O / FV-O
4 Thermal resistance ≤ 2.0 ordm;C /W 1
5 Surface Resistivity A ≥ 1 × 10 5 M Ω 5 × 10 7
Constant humidity treatment ≥ 1 × 10 5 M Ω 2 × 10 6
(90%,3 5 ordm;C,96h)

6 Volume Resistivity A ≥ 1 × 10 6 M Ω· m 4 × 10 8
Constant humidity treatment ≥ 1 × 10 6 M Ω· m 5 × 10 7
(90%,3 5ordm;C ,96h)

7 Dielectric Breakdown ( DC ) ≥ 28.5 Kv/mm 31
8 Dielectric constant (1MHz ) ≤ 4.4 / 4.2
(40 ordm;C,93% , 96h )

9 Dielectric dissipation factor (1MHz ) ≤ 0.03 / 0.02
(40 ordm;C, 93% ,96h )

RoHS Circuit Board Manufacturer Aluminum Base 2835 LED SMD PCB Board 1
