Thick 1.0mm 1.6mm Single Sided PCBs OSP LED Light Circuit Boards
2PCS
MOQ
large.img.alt
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: Yizhuo
Certification: CE,ROHS,UL
Model Number: Single Side PCB 04
High Light:

Thick 0.2mm Single Sided PCBs

,

Thick 4.0mmSingle Sided PCBs

,

0.2mm LED Light Circuit Boards

Payment & Shipping Terms
Packaging Details: Inner vacuum packing,Outer standard carton box packing.
Delivery Time: 10-12 work days
Payment Terms: T/T, Western Union
Specifications
Material: Aluminum
Quality Grade: Ipc Class 2, Ipc Class 3
Silk Screen: White,black,yellow
Board Thickness: 0.8mm- 2.0mm
Usage: Portable Audio Player
Surface Finishes: OSP, HASL, HASL Lf, Immersion Gold, Etc.
Product Description

Thick 1.0mm 1.6mm Single Sided PCBs OSP LED Light Circuit Boards



OSP surface finished Aluminum material led pcb board Circuit Board



Introduction of Aluminum PCB:

Aluminum PCB is the PCB type that used the low alloyed Al-Mg-Si with high plasticity alloy plate as the substrate material that has better thermal conductivity, electrical insulation, and machining performance, compared with the traditional FR4 PCB.



Similar to other types of PCBs, Aluminum PCB is structured by the conductive layer (copper layer); insulation layer (dielectric layer); and the substrate layer.



Aluminum PCB is capable to stand higher current with the same thickness and line width. Aluminum PCB is able to withstand voltage up to 4500V and thermal conductivity is more than 2.0. At present, aluminum PCB is the most common type for LED lighting PCB applications.



Common LED PCB has two sides. The top side with white solder mask is used for soldering SMD LED beads, and the other side normally has no solder mask and showing as aluminum metal color. If there is a demand for high-power heat dissipation, the aluminum base can also be coated with a thermal conductive silicone grease layer to connect with the installed heatsinks for better heat dissipation.



1
Description
PCB Specification
2
Material
FR-4/HTG150-180 FR-4/CEM-1/CEM-3/Aluminum
3
Layer
1-20
4
Board Thickness
0.2mm- 4.0mm
5
Board Thickness Tolerance
+/-10%
6
Copper thickness
17.5um-175um (0.5oz-5oz)
7
Min Trace Width
0.15mm
8
Min Space Width
0.15mm
9
Min Drilling Dia
0.2mm
10
PTH copper thickness
0.4-2mil(10-50um)
11
Tolerance of Etching
±1mil(±25um)
12
V-cut angle
25°,30°,45°,60°
13
Pearl Strength of line
≥ 6lb/in(≥ 107g/mm)
14
Impedance control and tolerance
50Ω±10%
15
Twist&Wrap
≤ 0.5%
16
Soldermask
Green, Red, Blue, White, Black, Yellow
17
Surface Finish/Plating
HASL/Lead Free HASL/OSP/Gold Plating/Immersion Gold/ENIG



Thick 1.0mm 1.6mm Single Sided PCBs OSP LED Light Circuit Boards 0

Thick 1.0mm 1.6mm Single Sided PCBs OSP LED Light Circuit Boards 1


FAQ:

Q1.  Are you a factory or trade company?

A:  We have our own PCB manufacturing & Assembly factory.



Q2:  Are all your products certified with UL, ROHS etc?

A:  Yes, we are certified to ISO9001:2015, ISO14001:2015, IFA,  UL , SGS, ROHS.



Q3:  How about the Shipping cost?

A:  The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.
