Metal Substrate 94V0 SMD 5730 LED Aluminum PCB
2PCS
MOQ
large.img.alt
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: Yizhuo
Certification: CE,ROHS,UL
Model Number: 94V0 Mcpcb Board
High Light:

SMD 5730 LED Aluminum PCB

,

94V0 LED Aluminum PCB

,

Metal Substrate MCPCB Board

Payment & Shipping Terms
Packaging Details: Inner vacuum packing,Outer standard carton box packing.
Delivery Time: 10-12 work days
Payment Terms: T/T, Western Union
Specifications
Product Name: 94V0 Mcpcb Board
Profiling Punching: Routing, V-CUT, Beveling
Silk Screen: White,black,yellow
Electrical Testing: Fixture / Flying Probe
Hole Tolerance: PTH: ±0.075, NTPH: ±0.05
Service: One-stop Service
Product Description

Aluminum LED PCB 94V0 Mcpcb Board Smd 5730 Circuit Board

YiZhuo PCB makes Aluminum PCBs, the most popular among metal core boards. Our aluminum substrate PCBs use aluminum core as the base material, and standard FR4 over it. The aluminum base acts as a thermal clad layer for dissipating heat efficiently, keeping heat producing components cool, thereby increasing the overall performance of the board and the device. Among all the aluminum-based PCB manufacturers, our customers consider our aluminum PCBs as the most useful solution to high power applications.




PCBA Capabilities
Turnkey PCBA
PCB+components sourcing+assembly+package
Assembly details
SMT and Thru-hole, ISO SMT and DIP lines
Lead Time
Prototype: 15 work days. Mass order: 20~25 work days
Testing on products
Flying Probe Test, X-ray Inspection, AOI Test, Functional test
Quantity
Min quantity: 1pcs. Prototype, small order, mass order, all OK
Files needed
PCB: Gerber files(CAM, PCB, PCBDOC)
Components: Bill of Materials(BOM list)
Assembly: Pick-N-Place file
PCB Panel Size
Min size: 0.25*0.25 inches(6*6mm)
Max size: 20*20 inches(500*500mm)
PCB Solder Type
Water Soluble Solder Paste, RoHS lead free
Components details
Passive Down to 0201 size
BGA and VFBGA
Leadless Chip Carriers/CSP
Double-sided SMT Assembly
Fine Pitch to 0.8mils
BGA Repair and Reball
Part Removal and Replacement
Component package
Cut Tape,Tube,Reels,Loose Parts
PCB assembly process
Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave
Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing



Aluminum LED PCB introduction:



Regular aluminum PCBs usually have three major layers:

  •  Copper Layer
  •  Insulating Layer
  •  Metal Substrate

COPPER LAYER

For the copper layer, we typically use electrolytic copper foil, which we etch to form the printed circuit. This layer holds the SMD components and copper traces on the layer form the necessary interconnections. When compared to a traditional FR4 PCB of the same line width and copper weight, the presence of the aluminum base allows the board to carry more current without heating up.

INSULATING LAYER

Forming the core of the board, the insulating layer functions as the electrical insulator, heat conductor, and the bonding material between the copper layer and the aluminum substrate. In the entire buildup, the insulating layer also acts as a thermal barrier for the heat flow from the circuit to the aluminum. Therefore, better the thermal conductivity of the insulating layer, better is the heat management, and lower is the temperature rise of the components. High thermal conductivity not only increases the power output, it also extends the life-span of the board.

METAL SUBSTRATE

We choose a metal for the substrate depending on several factors such as cost, weight, hardness, strength, thermal coefficient of expansion, and thermal conductivity.

A comparative comparison of various metals for cost and technical performance as above shows aluminum to be the optimum choice. Aluminum plates are available as 1000, 1060, 6061, and so on. Depending on requirements for even higher thermal conductivity and mechanical properties, we use other metals in place of aluminum. These include stainless steel, copper, iron, and silicon steel.



Metal Substrate 94V0 SMD 5730 LED Aluminum PCB 0




Aluminum LED PCB of Application:

Lamps and Lighting: This area of applications is the largest for aluminum PCBs. LEDs and other energy saving lamps and lighting systems in the market use aluminum PCBs in large scale.



Power Modules: Rectifier bridges, solid-state relays, inverters, and other power modules use aluminum PCBs.



Computer Electronics: Power supplies, CD and DVD drives, hard disk drives, and Mother boards use aluminum boards extensively.



Automotive Sector: Power supply controllers, ignition, electronic regulators, lamp drivers, motor controllers make extensive use of aluminum boards.



Office Automation: Power supplies, motor drives, printer heads, and other power modules use aluminum PCBs.



Communication Equipment: Transmitter circuit boards, filtering equipment, high frequency amplifiers, antenna circuits typically use aluminum boards.



Power Supplies: Switching regulators, AC/DC converters, linear regulators use aluminum PCBs for thermal management.



Audio Equipment: Power amplifiers, pre-amplifiers, audio amplifiers, balanced/unbalanced amplifiers, input/output amplifiers make extensive use of aluminum PCBs.


Metal Substrate 94V0 SMD 5730 LED Aluminum PCB 1

If you are looking for a resource that will provide you with Single Sided PCB for LED Tube Light, PCB For LED Spotlight, PCB For LED Lamp, PCB for LED high bay, PCB for LED downlight, PCB board for LED tube, then you have just found it.

Shenzhen Yizhuo Electronics Co.,Ltd has been established in 2012 years, Our factory area more than 5,000 square meters. We have more than 100 workers and 20 employees.We are Aluminum PCB and FR4 PCB manufacturer,our products are widely used in lighting, Electronics, New Energy, Medical care ,Automotive and Other industries.Our PCB production capacity can reach 120000 sq.m/per month .

Metal Substrate 94V0 SMD 5730 LED Aluminum PCB 2


FAQ:
Q1.  Do you have MOQ limited?

A:  We don’t have any MOQ limited, the minimum order we accept is 1pcs.

Q2:  Are all your products certified with UL, ROHS etc?
A:  Yes, we are certified to ISO9001:2015, ISO14001:2015, IFA,  UL , SGS, ROHS.

Q3:  Do you offer guarantee for the products?
A:  Yes, we offer 2 years warranty to our products.
