1W 3W 5W 24W LED Light Double Sided PCB Circuit Board Aluminum Plate
2PCS
MOQ
large.img.alt
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: Yizhuo
Certification: CE,ROHS,UL
Model Number: Black Aluminum PCB
High Light:

24W LED Light Double Sided PCB

,

5W LED Light Double Sided PCB

,

3W LED Aluminum Plate PCB Board

Payment & Shipping Terms
Packaging Details: Inner vacuum packing,Outer standard carton box packing.
Delivery Time: 10-12 work days
Payment Terms: T/T, Western Union
Specifications
Standard: IPC-Class2/Class 3
Material: Aluminum Base
Min Line Width: Min Line Width
Board Thickness: 1.0/1.2/1.6mm
Surface Finishing: HASL,OSP,ENIG, Gold Finger
Certification: UL,RoHS, CE
Product Description

1W 3W 5W 24W LED Light Double Sided PCB Circuit Board Aluminum Plate



1W 3W 5W 24W LED Light Aluminum PCB Circuit Board Power Plate



1. Introduction of PCB Mount Led Aluminum PCB

Fastline Circuits is capable of providing full turnkey and partial turnkey printed circuit board assembly services. For full turnkey, we take care of the entire process, including preparation of Printed Circuit Boards, procurement of components, online order tracking, continuous monitoring of quality and final assembly. Whereas for partial turnkey, the customer can provide the PCBs and certain components, and the remaining parts will be handled by us.

Features-Our Products Advantage

1.  Over 10 years experience manufacturer in PCB Assemble and PCB field.
2.  Big scale of producing makes sure that your purchase cost is lower.
3.  Advanced production line guarantees stable quality and long life span.
4.  Produce almost any PCB as your requirement.
5.  100% test for all customized PCB products.
6.  One-stop Service ,we can help to purchase the components.

Metal Core PCB Capability



Materials

Aluminum ,copper

Maximum Lager Count

4 Layers

Maximum Panel Size

17″ x 23″ (432 x 584 mm2)

Min. Board Thickness

1.0mm Al, 4 mils (0.1 mm) FR4

Copper Clad (inner)

1/2 oz, 1 oz, 2 oz, 3 oz, 4oz

Copper Clad (outer)

1/2 oz, 1 oz, 2 oz, 3 oz, 4 oz

Surface Finishes

ENTEK 106A, Immersion Gold, HAL, immersion silver

Solder Mask

LPI: Taiyo PSR 4000, Tamura DS2200, Probimer 77MA

Minimum Trace (width)

12.0 mils (0.30 mm)

Minimum Trace (spacing)

12.0 mils (0.30 mm)

Minimum PAD-TO-PAD TOL.

± 3 mils (± 0.76 mm)

Hole Size Tolerance (NPTH)

± 2 mils (± 0.05 mm)

Hole Size Tolerance (PTH)

± 3 mils (± 0.076 mm)

Minimum Hole Size

20 mils (0.50 mm)

Outline Dimensional Tol.

< ± 10 mils (0.25 mm)

Ionic Cleanliness

< 5 mg/in2 of NaCl (0.775 mg/cm2)

Impedance Control

± 10% (Differential)

Warpage

< 1%
