Power 200w SMD LED Double Sided Aluminium PCB Custom Round Shape
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: China
Brand Name: Yizhuo
Certification: UL,CE,ROHS
Model Number: led board
High Light:

200w Double Sided Aluminium PCB


1.0mm Double Sided Aluminium PCB


1.0mm SMD LED PCB Board

Payment & Shipping Terms
Packaging Details: Vacuum Package
Delivery Time: 10-12 work days
Payment Terms: T/T
Supply Ability: 120000 sq.m/per month
Pcb Board Thickness: 1.0mm
Testing: Fixturer Testing Jig/flying Testing
Usage: Led Tube Light
PCBA Service: SMD SMT DIP Component Assembly
Silkscreen: White, Yellow, Black
Testing Service: Fly-probe,100% AOI Testing, 100% ET Testing,
Product Description

Power 200w SMD LED Double Sided Aluminium PCB Custom Round Shape


Led pcb Board 1W 3W High Power LED PCB Aluminum plate Circuit board


Base Material
FR-4  /Aluminum /CEM-1
Finised inner/outer copper thickness
Finished board thickness
Min hole size
Mechanical hole: 0.15mm Laser hole: 0.1mm
Controlled Impedance
Plugging vias capability
Outline profile
Rout/ V-cut/ Bridge/ Stamp hole
Surface treatment
HASL, HASL lead free, Immersion Gold, Immersion Tin, Immersion Silver, Hard gold, Flash gold, OPS...


Application of LED PCB

You may be wondering about the possible use cases of LED PCB. The applicable cases are many, but we will mention some of the popular ones.

1. Medical Industry

It will interest you to know that the medical industry is one of the major beneficiaries of the applications of LED PCB.

Most of the medical equipment you know or see in the hospital are made from LED PCB. The reason for that is because LED PCBs tend to provide more light than traditional circuit boards would.

Also, preference is made for lighting tools used during medical examinations and surgeries. To ensure that the circuit boards are functioning effectively, aluminium PCB will be used during the manufacturing process because it effectively transfers heat while maintaining the stability of the medical pieces of equipment when in use.

2. Telecommunications

Aside from being used in the medical sector, LED PCBs can also be used in the telecommunications industry. There are two major roles played by these circuit boards in telecommunication devices.

First, LED PCBs (especially those manufactured with aluminium PCB) effectively transfer and dissipate heat from the board. Thereby, you are confident that the circuit board will stand the test of time because it is not in immediate danger of malfunctioning because of overheating.

Second and most important, LED PCBs are used in the telecommunication sector because of the boards of the overall importance of the displays and indicators on the boards in telecommunication equipment.

3. ICT and Tech

If you are conversant with how the IT industry works, you will understand why LED PCBs are mostly used instead of the other circuit boards. For instance, computers and Personal Computers (PCs) heat the most after some hours of use. That could cause damages to the internal components of the computers.

However, if the PCs and computers were manufactured with LED PCBs, the damages will be limited because of the effective dissipation of heat from the circuit board.

4. Automotive Industry

This time, we are looking at how LED PCBs can be the last resort for automobile manufacturers that want to improve on the quality and effectiveness of their indicators and brake lights.

LED PCBs are mostly preferred during automobile production because of their increased efficiency and competitive pricing.

5. Additional Use Cases

The four (4) applications of LED PCBs are not the only ones. Instead, there are several other applications and use cases of the circuit boards you need to know about.

First, LED PCBs are used in producing consumer devices, such as:

  • Power converters

  • Aviation applications

  • Decorative lights

  • Marine applications

  • Lower-light environments

  • Concealed light

  • Flashlight

  • Elevator lighting and

  • Camping accessories
