Surface OSP Double Sided PCB Clad Board In Led Lighting Industry
2PCS
MOQ
large.img.alt
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: Yizhuo
Certification: CE,ROHS,UL
Model Number: Aluminum Pcb Board 01
High Light:

OSP Double Sided PCB

,

Beveling Double Sided PCB

,

OSP PCB Clad Board

Payment & Shipping Terms
Packaging Details: Vacuum Package+ Good quality carton box
Delivery Time: 10-12 work days
Payment Terms: T/T, Western Union, MoneyGram
Specifications
Base Material: Aluminum Base
Copper Thickness: 1/2OZ
Peelable: 0.3-0.5mm
Profiling Punching: Routing, V-CUT, Beveling
Service: One-stop Service
Keyword: PCB Clad Board
Surface: OSP
Product Description

Surface OSP Double Sided PCB Clad Board In Led Lighting Industry



Pcb Clad Board Pcbs And Their Applications In The Led Lighting Industry



ABOUT ALUMINUM PCBS

Most common among metal-core printed circuit boards is the aluminum PCB. This type of printed circuit board is built on top of an aluminum alloy base, instead of a fiberglass base. The alloy usually consists of a combination of magnesium, aluminum and silumin, altering the properties of the metal to best suit the needs of the application.
All aluminum PCBs consist of the following layers:

  • The Base Layer: The base layer of the PCB is the aluminum alloy sheet upon which the rest of the PCB builds. This alloy is typically designed to provide maximum electrical insulation and thermal conductivity.

  • The Thermal Insulation Layer: This layer is extremely important in the design of the PCB. Consisting of a ceramic polymer, this layer protects the PCB from mechanical or thermal damage by offering thermal resistance and viscoelastic properties. This works by absorbing the heat created as the current moves through the circuits and transferring it to the aluminum layer — there it disperses.

  • The Circuit Layer: This layer contributes most to the end function of the board, containing the copper foil circuits needed for the PCB to function.

These layers occur in any number of variations, with one or several thermal and circuit layers depending on the particular application. The layers listed also lend a number of different benefits to aluminum PCBs, which can be of use to several key industries.





LAYER

PROTOTYPE

MASS PRODUCTION (above 20 m2)

Quick Turn

Standard Time

MC PCB

48 hours

4-5 days

10-12 days

PFC 1 L

48 hours

5-6 days

12-13 days

1L

24 hours

3-4 days

8-10 days

2L

24 hours

3-4 days

8-10 days

4L

48 hours

5-6 days

8-10 days

6L

72 hours

6-7 days

10-12 days

8L

72 hours

7-8 days

12-14 days

10L

96 hours

9-10days

16-18 days

Surface OSP Double Sided PCB Clad Board In Led Lighting Industry 0


Surface OSP Double Sided PCB Clad Board In Led Lighting Industry 1
