OSP Two Layer PCB Multilayer Flexible Hybrid Through Hole Aluminum



Two Layer Pcb Pcbs And Their Applications In The Led Lighting Industry



ALUMINUM PCB TYPES

There are numerous ways the layers above can be altered to create new PCB designs. Each of these variations results in slightly different qualities of the PCB, making it more suitable for some industries and applications over others.

Some types of Aluminum PCBs include:

  • Flexible Aluminum: This relatively new material uses ceramic fillers and polyimide resin to provide excellent insulation and flexibility, all while retaining the aluminum’s impressive thermal conductivity. These PCBs can be formed to connect directly where they are needed. This eliminates the need for cables, connectors and fixtures, which can add to the end cost of the product. Once they are bent, however, they are meant to stay there — these PCBs are not designed to flex constantly.

  • Hybrid Aluminum: Just as it sounds, a non-thermal material fused to an aluminum base metal creates hybrid aluminum. Usually, the material is a circuit board made with conventional FR-4. By fusing these layers together, the circuit board can dissipate heat more effectively, as well as increase rigidity. These hybrids also tend to be less expensive than entirely aluminum products. The downside, however, is the loss of flexibility.

  • Multilayer Aluminum: In high-performance power-supply applications, multilayer aluminum PCBs are generally the best. These PCBs consist of layers of thermally conductive dielectrics. While this multilayer approach can handle high performance, they tend to be less efficient when it comes to transferring heat However, overall these PCBs tend to be effective for basic heat dissipation in more complex designs.

  • Through-Hole Aluminum: For more complex constructions, the aluminum base of a PCB can be pre-drilled and back-filled with dielectric before being laminated with thermal materials. These are highly complex and tend to be labor-intensive projects meant for particularly complicated or specific projects.

Of these aluminum PCB types, flexible and hybrid varieties tend to see the most use in industries like the LED lighting industry.





LAYER

PROTOTYPE

MASS PRODUCTION (above 20 m2)

Quick Turn

Standard Time

MC PCB

48 hours

4-5 days

10-12 days

PFC 1 L

48 hours

5-6 days

12-13 days

1L

24 hours

3-4 days

8-10 days

2L

24 hours

3-4 days

8-10 days

4L

48 hours

5-6 days

8-10 days

6L

72 hours

6-7 days

10-12 days

8L

72 hours

7-8 days

12-14 days

10L

96 hours

9-10days

16-18 days
