1.6mm Double Sided Printed Circuit Board Custom Prototype Service
Double side PCB Led pcb board aluminum circuit boards custom service
MULTILAYER ALUMINUM PCBS:
Common in the high performance power supply market, multilayer IMS PCBs are made from multiple layers of thermally conductive dielectrics. These constructions have one or more layers of circuitry buried in the dielectric with blind vias acting as either thermal vias or signal vias. While more expensive and less efficient at transferring heat as a single layer designs, they provide a simple and effective solution for heat dissipation in more complex designs.
Aluminum PCB is a Printed Circuit Board that contains a thin layer of conductive electrical insulator material. They are also known as Aluminum base, Aluminum clad, IMS (Insulated Metal Substrate), MCPCB (Metal Clad Printed Circuit Board), Thermally Conductive PCBs, etc. Aluminum PCBs were developed in the 1970s, soon after which their demand increased dramatically. The first application was their use in Amplification Hybrid Circuits. Currently, they are being used at a much larger scale and it is important for us to know about Aluminum PCB and their importance in the community.
Every flexible and unbending printed circuit board (PCB) design is different. It is customized to meet the board’s purpose. The same is true for the PCB base material, fiberglass is a popular base material, but aluminum-based PCBs are also very operative in many applications. Aluminum PCBs consist of a copper-clad laminate that delivers high performance, metal-based, including excellent electrical insulation and thermal conductivity.
|
Quantity
|
Min quantity: 1pcs. Prototype, small order, mass order, all OK
|
|
Files needed
|
PCB: Gerber files(CAM, PCB, PCBDOC)
|
|
Components: Bill of Materials(BOM list)
|
|
|
Assembly: Pick-N-Place file
|
|
|
PCB Panel Size
|
Min size: 0.25*0.25 inches(6*6mm)
|
|
Max size: 20*20 inches(500*500mm)
|
|
|
PCB Solder Type
|
Water Soluble Solder Paste, RoHS lead free
|
|
Components details
|
Passive Down to 0201 size
|
|
BGA and VFBGA
|
|
|
Leadless Chip Carriers/CSP
|
|
|
Double-sided SMT Assembly
|
|
|
Fine Pitch to 0.8mils
|
|
|
BGA Repair and Reball
|
|
|
Part Removal and Replacement
|
|
|
Component package
|
Cut Tape,Tube,Reels,Loose Parts
|
|
PCB assembly process
|
Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave
Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing |
FAQ:
Q1. How can I get a sample to check your quality?
A: After price confirmation,you can place orders for samples for your testing and evaluation.
Q2: Are all your products certified with UL, ROHS etc?
A: Yes, we are certified to ISO9001:2015, ISO14001:2015, IFA, UL , SGS, ROHS.
