Power 1W 3W Aluminum LED PCB For SMD Diode Bead Components Series
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: China
Brand Name: Yizhuo
Certification: CE,ROHS,UL
Model Number: led light pcb 01
High Light:

3W Aluminum LED PCB


1W Aluminum LED PCB


3W LED Printed Circuit Boards

Payment & Shipping Terms
Delivery Time: 10-12 work days
Payment Terms: T/T, Western Union
Product Name: Aluminum Pcb Board
Material: Aluminum
Copper Thickness: 1/2OZ 1OZ 2OZ 3OZ,1/3oz ~6oz
Min. Line Spacing: 0.1mm4mil
Type: Customized
Application: Led Light Pcb Board Design
Product Description

Power 1W 3W Aluminum LED PCB For SMD Diode Bead Components Series


1w 3w power LED printed circuit boards PCB for SMD diode bead components series

Detailed Product Description



Base Aluminum



Cu Thickness:


Thermal Conductivity:


Solder Color:

Black White Green According Customization



Surface Finished:



PCB Type

Material Type

Material Brand

Single side pcb
Double side pcb
Multilayer pcb
Single side pcb


5052 Series


The advantage of us


We have our own, independent of the wastewater treatment system.Make sure there will be a very big development space and the stability of the production environment in the futurer


Flexible operation, can be in the production of small batches.Also can produce large quantities.Can save production quickly.


The urgent double sample production for 24 hours, The urgent Multilayer sample production for 48 hours.completely according to customer requirements

About the Files


You have gerber files or PCB files


You have PCB samples. send to us the sample. we will help for free copy it


How to calculate the price


For example, your double sided PCB size is 100 mm * 200 mm wide, long double sided PCB price is $60 a square meters.So the calculation results 100MM*200MM*$60/1000000=$1.2

1 inch=25.4mm


About the transportation.

All the quotation does not include the transportation cost



You find a freight forwarding company to help you, When we finished the PCB ,We wiill send to your forwarder company directly .You directly to the transport charges paid to forwarder company


We help you responsible for transport, freight included in the price.According to how much money a kilogram computation.


In order to save costs.The best is you have familiar forwarder company



Established in the year 2014, we “R Square SMD Solution” are a prominent firm that is engaged in manufacturing a wide range of Tube Light Driver And Fixture, Tube Light Housing, LED Tubelight, LED PCB, LED Flood Light, etc. Located in Ahmedabad (Gujarat, India), we are Partnership firm and manufacture the offered products as per the set industry norms. Our valued clients can avail these products from us at reasonable rates. We sell these products under the brand name ‘QLux’. Under the headship of “Miss. Hiral Dhakan” (Sales Manager), we have gained a remarkable and strong position in the market.


Process Capability



Material Type: FR4/Aluminum/Ceramic/CEM-1/Copper/polytef

Cooper thickness: 0.5-12OZ

Board Thickness: 0.2-6.0mm

Min hole size: 0.25mm( finished hole size)

Min Line Width/spacing:0.08mm

Drilling accuracy:+/-0.05

Max working size:520*620mm(21.25x24.5inch)

Min Inner layer thickness:0.1mm

Min thickness Board for HAL surface finished:0.4mm

Certificate: Rohs, Iso9001, UL(in certification)

Min thickness 4 layer: 0.4mm

Min thickness 6 layer:0.6mm

Min/Max layer count : 1/20

Lamination evenness :+/-0.05mm

Min SMD Pitch : 0.125mm

Min Dam Between Fine Pitch: >0.1mm

Layer to Layer registration:<0.1mm

Impedance control:+/-5%

Differential impedance:+/-10%

Board bow/twist tolerance:<0.7%

Plating spect ratio: <8:1

Plating COV: <10%

Surface Finished: LF-HASL ,Immersion Gold/Tin/Silver ./Plating Gold/OSP,

PTH backlight : 9-9.5 level

Solder Mask:Green , Red, Blue,White, Black,Yellow.

Plating extensibility:>15%


Power 1W 3W Aluminum LED PCB For SMD Diode Bead Components Series 0

Why Choose Us

1) Shenzhen Yizhuo Electronics Co.,Ltd has been established in 2012 years, Our factory area more than 5,000 square meters,120 workers

2) We have good quality control systems, including ISO 9001:2008;

3) Our factory has CE, ROHS, UL certification

4) All the components we use are the New & Original;

5) One-stop service can be provided from PCB design, 1-32 layers PCB manufacturing, components sourcing, PCB Assembly, to Fully Product Assembly.

Power 1W 3W Aluminum LED PCB For SMD Diode Bead Components Series 1


Power 1W 3W Aluminum LED PCB For SMD Diode Bead Components Series 2



Q1: Do you have any minimum order quantity requirement?

A: no, the sample you just need a minimum of 2 pieces.


Q2. What is needed for PCB PCBA quotation?

A:  PCB: Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ,...)


Q3: How about the Shipping cost?

A:  The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.
