Single Sided 94V0 PCBA Circuit Board OEM ODM Design Metal Core
Single Sided ROHS 94V0 Aluminum Led Light Pcb Custom ODM Design
|
Layer |
1-2 layers |
|
Board thickness |
0.2mm-6.0mm |
|
Copper thickness |
0.5oz-6.0 oz |
|
Wattage |
18W 30W 36W |
|
Min. hole diameter |
0.1mm |
|
Min. line width |
0.075mm |
|
file format |
pcb,doc,ddb etc |
|
Warranty |
2 Years |
|
Base material |
Aluminium |
|
Solder mask |
green, red, blue, yellow, black, white etc |
|
Surface finish |
ENIG, ImAg, ImSn, OSP, HASL, |
Benefits of Aluminum PCBs:
There are quite a few advantages of using aluminum printed circuit boards.
The dissipation of heat in aluminum is much better and far superior to standard FR4 material. When compared to Copper PCBs, aluminum PCBs offer better heat dissipation.
InFR4 PCBs,the dielectrics are not thin and don’t offer a good thermal conductivity. On the other hand, the dielectric utilized in aluminum PCBs are one-tenth of the thickness and provide up to 5 to 6 times the thermal conductivity of epoxy glass.
The thermal transfer exponent is more efficient than that of a rigid PCB.
Since aluminum is around 70 percent lighter than copper, aluminum printed circuit boards are a better alternative to copper based printed circuit boards.
An LED PCB board tends to generate a high volume of heat, making it difficult to cool via traditional means. Consequently, metal core PCBs are frequently chosen for LED application due to their enhanced ability to dissipate heat. Aluminum in particular is often used to manufacture circuit boards for LED lights. The aluminum PCB typically includes a thin layer of thermally conductive dielectric material that can transfer and dissipate the heat with much greater efficiency than a traditional rigid PCB.
