UL Certified 1.6mm Single Side Aluminium LED PCB Board
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: China
Brand Name: Yizhuo
Certification: UL,CE,ROHS
Model Number: custom led pcb1
High Light:

1.6mm Aluminium LED PCB Board


UL Certified Aluminium LED PCB Board


1.6mm Aluminum LED PCB

Payment & Shipping Terms
Packaging Details: Vacuum Package
Delivery Time: 10-12 work days
Payment Terms: T/T
Supply Ability: 120000 sq.m/per month
Layer: 1-2 Layers
Testing: Fixturer Testing Jig/flying Testing
Certificate: ISO9001:2008,ROHS,UL
Surface Finishing: HASL Lead Free
Silkscreen: White, Yellow, Black
Custom Service: SMT Led Chips
Product Description

Single-side Aluminium Board LED PCB 1.6mm Printed Circuit Board



Item Capability
1. Base Material FR-4 /ALUMINUM
2. Layers 1-2
3. Finised inner/outer copper thickness 1-10OZ
4. Finished board thickness 0.2-7.0mm

Board thickness≤1.0mm: +/-0.1mm

1<Board thickness≤2.0mm: +/-10%

Board thickness>2.0mm: +/-8%

5. Max panel size

≤2sidesPCB: 600*1500mm

Multilayer PCB: 500*1200mm

6. Min conductor line width/spacing

Inner layers: ≥3/3mil

Outer layers: ≥3.5/3.5mil

7. Min hole size

Mechanical hole: 0.15mm

Laser hole: 0.1mm

Drilling precision: first drilling

First drilling: 1mil

Second drilling: 4mil

8. Min welding ring 4mil
9. Min solder mask bridge ≥0.08mm



UL Certified 1.6mm Single Side Aluminium LED PCB Board 0

The Aluminum PCB Manufacturing process:

1. Cutting lamilate

2. Drilling

3. Dry/wet film Developing

4. Acid/alkaline etching

5. Silk screen solder mask

6. V-CUT

7. Test, organic solderability preservative (OSP)

8. Final quality control (FQC), final quality assurance (FQA), packaging, shipping

UL Certified 1.6mm Single Side Aluminium LED PCB Board 1


PCBs that require a lot of power usually generate a lot of heat. If your PCBs need fast cooling it is better to use Metal Core PCB than FR4. The following list includes some of the most popular applications that work great with this technology:

  • LED Lighting
  • Celling lamp
  • Wall lamp
  • Garden lamp
  • Automotive Electronics

UL Certified 1.6mm Single Side Aluminium LED PCB Board 2


Q1. How long is the lead time?
A: For samples, it will take 5-7 work days; for bulk orders, it will take 10-15 work days..
Q2. How can I get a sample to check your quality?
A: After price confirmation,you can place orders for samples for your testing and evaluation.
Do you offer guarantee for the products?
A: Yes, we offer 2 years warranty to our products.
