HASL LED 35 - 70um Thickness Heavy Copper PCB 94V0
1PCS
MOQ
large.img.alt
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: Yizhuo
Certification: CE,ROHS,UL
Model Number: Copper pcb 06
High Light:

70um Thickness Heavy Copper PCB

,

HASL Heavy Copper PCB

,

PCB LED Board 94V0

Payment & Shipping Terms
Packaging Details: Vacuum Package+ Good quality carton box
Delivery Time: 5-10work days
Payment Terms: T/T, Western Union
Supply Ability: PCB production capacity can reach 120000 sq.m/per month
Specifications
Material: Copper
PCB Standard: IPC-II Standard
Copper Thickness: 35-70um
Service: LED PCBA Assemblely
Led Pcb Board Dimension: Round /square Rectangle / Custom
Application: Home Appliances, Electronics, Led Lighting
Product Description

Heavy Copper Pcb Aluminum HASL 94v0 pcb led board Fabrication


Heavy Copper PCB introduction:

Thick copper PCBs have finished copper weights of over 4oz (140μm), compared to the 1oz (35μm) and 2oz (0μm) copper weights typically found in standard boards. The extra copper thickness allows the PCB to carry more power, establish high thermal circulation, and perform complex switches in a small space.



Heavy copper PCBs are highly used for high power and current applications in power supplies, welding equipment, electrical power distribution, power converters, solar panel devices, medical, automotive, aviation and etc. because the heavy copper layers are helpful for controlling the thermal dissipation and running high power and current. Our heavy copper PCB manufacturing service covers single-sided, double-sided and multilayer PCBs.





Place of Origin
Guangdong, China
Base Material
Copper
Min. Line Width
3mil
Brand Namey
YiZhuo
Copper Thickness
1 Oz
Board Thickness
1.6mm
Min. Line Spacing
3 Mil (0.075 Mm)
Surface Finishing
HASL Lead Free
Min. Hole Size
0.10mm
sample
welcome
Testing Service
Function Test
Solder masks color
Green,black,blue,red, white
Product name
PCB Board Assembly
Type
Electronic Board
ODM
yes
Custom logo
yes



HASL LED 35 - 70um Thickness Heavy Copper PCB 94V0 0

Benefits of Heavy Copper PCBs:

Heavy base copper PCBs offer several advantages such as:

  • Reduced wired buss configurations lead to small PCB size
  • Easy integration with high-power circuits and control circuits
  • Enhanced thermal resistance reduction with addition of copper plating in the heat vias
  • Increased current carrying capacity, as well as endurance to thermal strains
  • Reduced layer count due to easy incorporation of multiple copper weights on a single layer
  • Enhanced mechanical strength in PTH Holes and connector sites
  • Allow use of exotic materials to their full potential without causing circuit failure
  • Heavy copper plated vias carry high current through the circuit board, as well as help transfer heat to the heatsink in the exterior.
  • The PCBs can withstand high thermal cycling



Industrial Applications Using Heavy Copper PCBs:

  • Solar Power Converters
  • Overload Relays
  • High Power Rectifiers
  • Power Converters for Railway Electrical Systems
  • Safety and Signal Systems
  • Traction Converters for Railway Applications
  • Protection Relays
  • Excitation Systems for Power Regulators
  • HVAC Systems
  • Nuclear Power Applications
  • Weapons Control Systems
  • Power Supplies for Radar Systems
