Led Pcb Manufacture SMD 2835 Print Circuit Component Custom Size
2PCS
MOQ
large.img.alt
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: Yizhuo
Certification: CE,ROHS,UL
Model Number: led pcb board 15
High Light:

SMD 2835 Aluminum LED PCB

,

Custom Size Led Light Circuit Board

,

OEM Smd Led Pcb Board

Payment & Shipping Terms
Packaging Details: Inner vacuum packing,Outer standard carton box packing.
Delivery Time: 10-12 work days
Payment Terms: T/T, Western Union
Specifications
Product Name: Led Pcb
Profiling Punching: Routing, V-CUT, Beveling
Silk Screen: White,black,yellow
Electrical Testing: Fixture / Flying Probe
Hole Tolerance: PTH: ±0.075, NTPH: ±0.05
Service: One-stop Service
Product Description

Led pcb manufacture smd 2835 print circuit component custom size



Aluminum led pcb types:

There are numerous ways the layers above can be altered to create new PCB designs. Each of these variations results in slightly different qualities of the PCB, making it more suitable for some industries and applications over others.

Some types of aluminum printed circuit boards include:

  • Flexible aluminum: This relatively new material uses ceramic fillers and polyimide resin to provide excellent insulation and flexibility, all while retaining the aluminum’s impressive thermal conductivity. These PCBs can be formed to connect directly where they are needed. This eliminates the need for cables, connectors and fixtures, which can add to the end cost of the product. Once they are bent, however, they are meant to stay there — these PCBs are not designed to flex constantly.
  • Hybrid aluminum: Just as it sounds, a non-thermal material fused to an aluminum base metal creates hybrid aluminum. Usually, the material is a circuit board made with conventional FR-4. By fusing these layers together, the circuit board can dissipate heat more effectively, as well as increase rigidity. These hybrids also tend to be less expensive than entirely aluminum products. The downside, however, is the loss of flexibility.
  • Multilayer aluminum: In high-performance power-supply applications, multilayer aluminum PCBs are generally the best. These PCBs consist of layers of thermally conductive dielectrics. While this multilayer approach can handle high performance, they tend to be less efficient when it comes to transferring heat. However, overall these PCBs tend to be effective for basic heat dissipation in more complex designs.
  • Through-hole aluminum: For more complex constructions, the aluminum base of a PCB can be pre-drilled and back-filled with epoxy resin. These are highly complex and tend to be labor-intensive projects meant for particularly complicated or specific projects.

Of these aluminum PCB types, flexible and hybrid varieties tend to see the most use in industries like the LED lighting industry.



Layer
1~64 Layers
Material
FR4, CEM1, CEM3, Aluminum
Production Capacity
30000 ㎡/months
Board shape
Rectangular, Round, Slots, Cutouts, Complex Irregular
Board cutting
Shear, V-Score, Tab-Routed, Counter Sunk
Board thickness
0.2~8.0mm, Flex 0.1-0.25mm
Copper weight
0.5oZ~12oZ
Solder Mask
Double-sided Green LPI, Red, White, Yellow, Blue, Black, Purple etc.Solder mask
Silk screen
Double-Sided or Single-Sided in White, Yellow, Black etc
Min line width/space
0.08mm/3mil
Max board dimensions
25.6inch*43.3inch or 650mm*1100mm
Min drill hole diameter
0.1mm
Min Laser Drill hole diameter
0.075mm
Surface finish
HASL, ENIG, Immersion Tin, Immersion Silver, OSP,ENEPIG etc
Board thickness toleranc
± 10%
Min slot width
0.12",3.0mm,or 120mils
V-score depth
20-25% of board thickness
PTH Wall Thickness
>0.025mm
PTH Hole Dia Tolerance
±0.076mm
Non PTH Hole Dia Tolerance
±0.05mm
Hole Position Deviation
±0.076mm
Sink holes
Yes
Quality Standard
IPC-A600F/MIL-STD-105D
Design file format
Gerber RS-274X, 274D, Eagle and AutoCAD'S DXF,DWG

Led Pcb Manufacture SMD 2835 Print Circuit Component Custom Size 0

Some of Aluminum led pcb Application:



Led Pcb Manufacture SMD 2835 Print Circuit Component Custom Size 1

Shenzhen Yizhuo Electronics Co., Ltd. is a national high-tech enterprise certified to ISO9001: 2015 international quality management system. We have CE, ROHS, UL certification. It was founded in 2012 and factory area consists of more than 6,000 square meters, 131 employees, and two shifts. We have the capability to manufacture aluminum PCBs, FR4 PCBs, LED PCBA, and other related products. We are also providing services like PCB design, PCB assembly, and LED SMT board processing for PCB designing services. The products are widely used in lighting, electronics, communications, automotive and other industries that require heat dissipation. Our professionals work in close association to understand the specific requirements of our clients. In our quality testing unit, we meticulously test each product, thus results in their compliance with international quality standards. We can do ODM or OEM one-stop service for our customers.

Led Pcb Manufacture SMD 2835 Print Circuit Component Custom Size 2

Led Pcb Manufacture SMD 2835 Print Circuit Component Custom Size 3
