94v0 Electronic Aluminum Led PCB Boards Single Side Circuit Board
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: China
Brand Name: Yizhuo
Certification: CE,ROHS,UL
Model Number: led pcb board 16
High Light:

94v0 Aluminum Led PCB Boards


LED lighting Single Side Circuit Board


CE Certificate Led PCB Boards

Payment & Shipping Terms
Packaging Details: Inner vacuum packing,Outer standard carton box packing.
Delivery Time: 10-12 work days
Payment Terms: T/T, Western Union
Product Name: Aluminum Led PCB Boards
Profiling Punching: Routing, V-CUT, Beveling
Silk Screen: White,black,yellow
Electrical Testing: Fixture / Flying Probe
Hole Tolerance: PTH: ±0.075, NTPH: ±0.05
Service: One-stop Service
Product Description

94v0 Electronic Aluminum Led PCB Boards Single side Circuit Board


Aluminum Led PCB BoardsTech Specifications:

Aluminum PCBs are mainly used in LED lighting, power supply, and motor drive modules.
• LED lighting: like most electronic components, heat is the biggest threat to LEDs. An LED generates much heat, which can affect its brightness, change the light color, and eventually fail it. To avoid the accumulation of heat in LEDs and keep a long time’s high brightness, aluminum PCBs are used in them to dissipate heat.

• Power supply: aluminum PCB is the only choice for the DC/AC converter due to the limitation of size and high power density. From PCBONLINE, you can buy aluminum PCBs with various performance parameters required by DC/AC converters.

• Motor drive module: motor drive modules require compact structure and high reliability. Whether an aluminum PCBs can meet hese requirements depends on the power density it can withstand. Only aluminum PCBs with high thermal conductivity and high reliability can meet the wide range requirements of a motor drive module. Shenzhen Yizhuo manufactures aluminum PCBs with good electrical insulation performance to meet the requirements of the module’s operation and safety testing.


1~64 Layers
FR4, CEM1, CEM3, Aluminum
Production Capacity
30000 ㎡/months
Board shape
Rectangular, Round, Slots, Cutouts, Complex Irregular
Board cutting
Shear, V-Score, Tab-Routed, Counter Sunk
Board thickness
0.2~8.0mm, Flex 0.1-0.25mm
Copper weight
Solder Mask
Double-sided Green LPI, Red, White, Yellow, Blue, Black, Purple etc.Solder mask
Silk screen
Double-Sided or Single-Sided in White, Yellow, Black etc
Min line width/space
Max board dimensions
25.6inch*43.3inch or 650mm*1100mm
Min drill hole diameter
Min Laser Drill hole diameter
Surface finish
HASL, ENIG, Immersion Tin, Immersion Silver, OSP,ENEPIG etc
Board thickness toleranc
± 10%
Min slot width
0.12",3.0mm,or 120mils
V-score depth
20-25% of board thickness
PTH Wall Thickness
PTH Hole Dia Tolerance
Non PTH Hole Dia Tolerance
Hole Position Deviation
Sink holes
Quality Standard
Design file format
Gerber RS-274X, 274D, Eagle and AutoCAD'S DXF,DWG

94v0 Electronic Aluminum Led PCB Boards Single Side Circuit Board 0

Aluminum Led PCB Boards design advantage:

Advancements in LED PCB design with aluminum cores have allowed for several new and improved capabilities. Aluminum transfers more heat from the printed circuit board and LEDs. Fiberglass PCBs have a limit on the density of LED lights they can accommodate due to heat build-up. Aluminum cores offer greater temperature control compared to standard cores or fiberglass bases.


The ability of aluminum to improve temperature control allows for the following benefits:

  • Higher LED density: More lights mean higher operating temperatures that require better thermal regulation from aluminum cores.
  • Longer operating time: Aluminum printed circuit board designs better remove excessive heat produced from long operating times.

Some of Aluminum Led PCB Boards Application:

94v0 Electronic Aluminum Led PCB Boards Single Side Circuit Board 1



Shenzhen Yizhuo Electronics Co., Ltd. is a national high-tech enterprise certified to ISO9001: 2015 international quality management system. We have CE, ROHS, UL certification. It was founded in 2012 and factory area consists of more than 6,000 square meters, 131 employees, and two shifts. We have the capability to manufacture aluminum PCBs, FR4 PCBs, LED PCBA, and other related products. We are also providing services like PCB design, PCB assembly, and LED SMT board processing for PCB designing services. The products are widely used in lighting, electronics, communications, automotive and other industries that require heat dissipation. Our professionals work in close association to understand the specific requirements of our clients. In our quality testing unit, we meticulously test each product, thus results in their compliance with international quality standards. We can do ODM or OEM one-stop service for our customers.

94v0 Electronic Aluminum Led PCB Boards Single Side Circuit Board 2

94v0 Electronic Aluminum Led PCB Boards Single Side Circuit Board 3


Q1.  Do you have MOQ limited?

A:  We don’t have any MOQ limited, the minimum order we accept is 1pcs.


Q2:  How about your supply capacity?

A:  Our supply capacity is around 2000sqm each day. where our 25 000 sqm factory space hosts R&D, marketing, logistics and procurement operations.


Q3:  Is it OK to print my logo on product?

A:  Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
