Aluminum PCB is one type of metal core printed circuit board (MCPCB), widely be used in LED lighting industry.
If you are looking for Aluminum PCB Manufacturer, Yizhuo has so many years of experience in manufacturing Aluminium PCB with high thermal conductivity , we offers a first class service and extensive high-tech options.
MCPCB, Metal Core PCB, thermal PCB – whichever name you prefer, they are all boards which use a base metal material as the heat spreader portion of the circuit board.These types of are typically fabricated with a metal base consisting of aluminum (most common) but can also be produced with copper.
|
1
|
Description
|
PCB Specification
|
|
2
|
Material
|
FR-4/HTG150-180 FR-4/CEM-1/CEM-3/Aluminum
|
|
3
|
Layer
|
1-20
|
|
4
|
Board Thickness
|
0.2mm- 4.0mm
|
|
5
|
Board Thickness Tolerance
|
+/-10%
|
|
6
|
Copper thickness
|
17.5um-175um (0.5oz-5oz)
|
|
7
|
Min Trace Width
|
0.15mm
|
|
8
|
Min Space Width
|
0.15mm
|
|
9
|
Min Drilling Dia
|
0.2mm
|
|
10
|
PTH copper thickness
|
0.4-2mil(10-50um)
|
|
11
|
Tolerance of Etching
|
±1mil(±25um)
|
|
12
|
V-cut angle
|
25°,30°,45°,60°
|
|
13
|
Pearl Strength of line
|
≥ 6lb/in(≥ 107g/mm)
|
|
14
|
Impedance control and tolerance
|
50Ω±10%
|
|
15
|
Twist&Wrap
|
≤ 0.5%
|
|
16
|
Soldermask
|
Green, Red, Blue, White, Black, Yellow
|
|
17
|
Surface Finish/Plating
|
HASL/Lead Free HASL/OSP/Gold Plating/Immersion Gold/ENIG
|
Applications of Aluminum PCB:
General lighting applications (Streetlight , Flashlight, Spotlight, etc.)
Back light unit applications
Back light unit applications
Power converters: telecom, high voltage regulator, power supplies
Hybrid/electric motor control applications
Photovoltaic
FAQ:
Q1. What are the main products of your PCB/PCBA services?
A: Industrial control, Automotive, Medical Equipment, Communication Electronics, Security Devices.
Q2: Are all your products certified with UL, ROHS etc?
A: Yes, we are certified to ISO9001:2015, ISO14001:2015, IFA, UL , SGS, ROHS.
Q3: How about the Shipping cost?
A: The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.
