Min Spacing 22mil Washing Machine PCB Board For Illumination Lighting
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: China
Brand Name: Yizhuo
Certification: CE,ROHS,UL
Model Number: PCB Circuit Board 03
High Light:

22mil Washing Machine PCB Board


ROHS Washing Machine PCB Board


22mil PCB Circuit Boards

Payment & Shipping Terms
Packaging Details: Inner vacuum packing,Outer standard carton box packing.
Delivery Time: 10-12 work days
Payment Terms: T/T, Western Union
Copper Thickness: 1oZ 2oZ 3oZ
Base Material: Aluminum
Min. Line Spacing: 22mil
Certificate: ISO9001:2008,ROHS,UL
Surface Finishing: HASL Lead Free ENIG
Application: Commercial Lighting, Office, School, Hospital Etc
Product Description

Min Spacing 22mil Washing Machine PCB Board For Illumination Lighting


OEM PCB Circuit Boards Washing Machine PCB Board For Illumination Lighting



As PCB technology has continued to evolve, it has paved the way for the creation of a host of exciting product innovations. A prime example is the development of the PCB for LED lighting. The LED is soldered to the circuit board and features a chip that produces the light when electrically connected. A thermal heat sink and a ceramic base are used to bond the chip.

An LED PCB board tends to generate a high volume of heat, making it difficult to cool via traditional means. Consequently, metal core PCBs are frequently chosen for LED application due to their enhanced ability to dissipate heat. Aluminum in particular is often used to manufacture circuit boards for LED lights. The aluminum PCB typically includes a thin layer of thermally conductive dielectric material that can transfer and dissipate the heat with much greater efficiency than a traditional rigid PCB.






Thicker Copper


Products Type

HF(High-Frequency)&(Radio Frequency) board, lmpedance
controlled board. HDl board.BGA& Fine Pitch board

Solder Mask

Nanya&Taiyo; LPl & Mattgreen,yellow,white,blue,black,red.

Base material

FR4(Shengyi China,  ITEQ, KBA+,HZ), Hl-TG.

FR06,Rogers Taconic, Argon, Nalco, lsola, aluminum and so on

Finished Surface

HASL.Lead-free HASL.Falsh Gold, ENIG(Immersion Gold).
OSP, lmmersion Tin.lmmersion Silver,Hard Gold

Technical Specification

Minimum line width/gap:3.5/4mll(laserdrill)
Minimum hole size:0.2mm(mechanical drill)/4mil(laser drill)
Minimum Annular Ring: 4mil
Max Copper thickness: 60Z
Board Thickness:D/S: 0.2-4.0mm.


Min Solder Mask Bridge:0.08mm

Aspect ratio: 8: 1
Plugging Vias capability: 0.2-0.8mm


Min Spacing 22mil Washing Machine PCB Board For Illumination Lighting 0


PCB LED Applications:

PCB LED lights can be incorporated into numerous lighting applications due to their combination of excellent energy efficiency, low cost and maximum design flexibility. Examples include Automotive headlights, Airport runway landing lights, Lighting used in military field applications, Street lighting, Highway tunnel lighting, Photovoltaic (solar) lighting, Flashlights and lanterns, Traffic and signal lighting, Lighting in hospital operating rooms, High growth plant lighting and many others.

Min Spacing 22mil Washing Machine PCB Board For Illumination Lighting 1
