12w 18w 24w 100W LED Light PCB Board Aluminum Base Dielectric Layer
2PCS
MOQ
large.img.alt
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: Yizhuo
Certification: CE,ROHS,UL
Model Number: Aluminum Pcb Board 01
High Light:

100W LED Light PCB

,

12w LED Light PCB

,

1.2mm 2835 LED PCB

Payment & Shipping Terms
Packaging Details: Vacuum Package+ Good quality carton box
Delivery Time: 10-12 work days
Payment Terms: T/T, Western Union
Specifications
Brand Name: Yizhuo
Base Material: Aluminum Base
Copper Thickness: 1/2OZ
Board Thickness: 1.2mm
Size: Customized
Service: One-stop Service
Product Description

12w 18w 24w 100W LED Light PCB Aluminum Base Dielectric Layer



Aluminum Pcb Board 5730 2835 for all LED light 12w 18w 24w 100W



Structure of Aluminum PCB:

Aluminum PCBs are aluminum based CCLs (CCL is a type of base material of PCBs). Aluminum PCBs are actually quite similar to FR4 PCBs. The basic structure of Aluminum PCBs is four layered. It consists of a layer of copper foil, a dielectric layer, an aluminum base layer and aluminum base membrane.

  • Copper Foil Layer: the copper layer used is relatively thicker than normal CCLs ( 1oz-10oz). A thicker layer of copper means a larger current carrying capacity.

  • Dielectric Layer: the Dielectric layer is a thermally conductive layer and is around 50μm to 200μm thick. It had a low thermal resistance and it suitable for its application.

  • Aluminum Base: The third layer isthe aluminum base which is made up of aluminum substrate. It has a high thermal conductivity.

Aluminum Base Membrane Layer: Aluminum base membrane is selective. It has a protective role by keeping the aluminum surface safe from scraping and unwanted etching. It is of two types i.e. Lower than 120 degree or around 250 degrees (anti high temperature).



Item

Craft Capacity

Layer

1-8Layers

Base Material for PCB

FR4, CEM-1, 22F, Aluminium, High Tg Material, High Frequence ROGERS Halogen-free Material

Thickness

0.6-2.4mm

Copper thickness

0.5-2OZ

Surface Treatment

HASL (Tin-Lead Free), ENIG(Immersion Gold), Immersion Silver , Gold Plating (Flash Gold), OSP, etc.

Soldermask

Green, White, Red, Yellow, Black, Blue, transparent etc

Min.line width

0.15mm

Min.line space

0.15mm

Min.hole size

0.25mm

E-Testing

100% E-Testing (High Voltage Testing);Flying probe testing

Certificate

SGS.UL. ROHS,CQC. ISO9001:2015

MOQ

5pcs

Applicable to

LED light, air conditioner,electric equipent,washing maching
